Cosmetics Bottle Series Blowing Molding Machine

This model is mainly designed for small capacity PET / PP / PETG / PCTG / TRITAN bottles, such as cosmetics, cleaning, medicine and health care, etc., with small occupied area, simple structure, easy operation, high stability and good energy saving effect

Applicable materials: PET / PP / PETG / PCTG / TRITAN
Blow Molding Process
Injection molded preform heated
Preform secured into blow mold
Preform stretched with core rod
Compressed air simultaneously blown in - preform inflates to mold:
Product is removed from mold
Finished product ready for next production stage
Click To Check The Video
Discover the Efficient Process Behind Our Blow Molding Equipment

Custom Cosmetics Bottle Blow Molding Machine For Your Specific Needs Project solution customization is one of our unique competitive advantages..We tailor each requirement to your unique project solution to achieve your project needs.
Max. product volume ml500-3000
Max. product diameter mm55-135
Max. neck diameter mm38-120
Max. product height mm240-280
Max. mold height mm180-220
Mold open stroke mm80-160
Mold base open stroke mm25-50
Mold central distance mm76.2-114.3
pcs38-84
Cavities1-4
Heating Unit2-4
Heating Section8
Rating power KW21-50


The Different Output Models You Can Choose
Output/Hours: 500-900BPH
Model: LD-AS1A
Size: 2.45*1.6*1.8m
Weight:1.5 Ton

Output/Hours: 800-1800BPH
Model: LD-XP2S
Size: 2.2*1.36*1.8m
Weight:2 Ton

Output/Hours: 900-2200BPH
Model: LD-AS2S
Size: 2.45*1.6*1.8m
Weight:2.5 Ton

Output/Hours: 900-1600BPH
Model: LD-DP2S
Size: 3.3*1.8*1.8m
Weight:3.5 Ton

Output/Hours: 800-3000BPH
Model: LD-XP4S
Size: 3.3*1.8*1.8m
Weight:4 Ton

Output/Hours: 1800-2500BPH
Model: LD-AS4S
Size: 4.3*1.9*1.8m
Weight:5 Ton

Output/Hours: 1600-2500BPH
Model: LD-DP4S
Size: 6.1*1.9*2.0m
Weight:6 Ton

Reviews From Real Customers
"We have been using LinkTech's stretch blow molding equipment for several years and have been consistently impressed with the quality of our bottles. The team at LinkTech provides exceptional service and support, making the entire process seamless and stress-free."

From: John Smith, CEO
"We recently purchased a new stretch blow molding machine from LinkTech and have already seen a significant improvement in our production efficiency. The equipment is top-notch and the technical support provided by LinkTech's team has been exceptional."

From: Sarah Lee, Production Manager
"We were hesitant to invest in new equipment, but after working with LinkTech, we are so glad we did. The quality of our bottles has never been better and the energy efficiency of the equipment has helped us save on production costs. The customer service and support provided by LinkTech have exceeded our expectations."

From: Tom Johnson
"We have been using LinkTech's stretch blow molding machines for over a decade and have never been disappointed. The equipment is reliable, efficient, and easy to use. Whenever we have needed technical support, the team at LinkTech has been quick to respond and has always provided expert guidance."
From: Mary Chen, Production Manager
Why Choose Link-tech Blowing Molding Machine
Frequently Asked Questions

This section contains a few FAQs that our customers ask. If your question is not here, contact us today, and we will answer directly.

1.What is stretch blow molding?

Stretch blow molding is a manufacturing process used to produce plastic bottles by stretching and blowing preforms into their desired shape.
2.How do you maintain a stretch blow molding machine?

Regular maintenance is important to ensure optimal machine performance, including cleaning, lubrication, and replacement of worn parts.
3.What are the key parameters that affect the stretch blow molding process?

Key parameters include temperature, pressure, blowing time, and stretch ratio.
4.What materials are commonly used in stretch blow molding?


The most common materials used in stretch blow molding are PET, PP, and PETG.
5.What is the typical production speed of a stretch blow molding machine?
Production speed varies depending on the specific machine and bottle design, but can range from 1000 to 8000 bottles per hour.
6.How do you optimize environmental conditions for stretch blow molding?

Environmental conditions such as temperature and humidity can be optimized by controlling the production environment and implementing appropriate measures to maintain consistent conditions.
7.What types of cosmetic bottles can be produced using stretch blow molding?

Stretch blow molding can be used to produce a wide range of cosmetic bottles, including those for shampoos, conditioners, lotions, and serums.
8.What are the advantages of using stretch blow molding for producing cosmetic bottles?

Stretch blow molding allows for precise control over bottle shape and size, as well as high production speed and low energy consumption.
